Surface Resistivity Meter SRM 01 (9V)

Surface Resistivity Meter (SRM 01) 9V

Enquiry Now

Minimum Order Quantity 1 Piece Onwards
Brand Blue Sky Infosys
Usage Laboratory, Industrial
Calibration Recommended every 12 months
Weight 160-170 GRMS (with Battery)
Warranty 12 months
Accessories included Surface to Ground Cord and Instrument Carry Case
Measurement Range 10^3 to 10^12 ohms
Measurement Accuracy Half decade
Resolution One decade
Indication Visual by different color LEDs
Power supply 9 V Battery
Test actuation Press to Test
Battery Status By Dual Color LED
Dimensions 135 x 70 x 25 mm


Application & Features:
9V Surface Resistivity Meter is an ultra-wide-range, battery operated, and portable instrument for measuring Surface Resistivity of virtually any flat surface. In the circuit industry, products such as packaging materials, component storage bags and trays, workbench surfaces, table and floor mats, conveyor belts, etc., have resistance values which need to conform to stringent specifications. Moreover, these values are expected to fall within specified limits. The Surface Resistivity meter can play a vital role in monitoring and be checking the resistivity characteristic of the above item.

It also has the unique additional feature of surface-to-ground measurement capability wherein the resistivity differential between any surface and any chosen ground can be determined. The surface resistivity is conveniently indicated by a row of LEDs covering a total of 10 decades from 10^3 to 10^12 ohms/square.

For more details, please feel free to email us at enquiry@blueskyinfosys.com
